AP3440
Document number: DS36691 Rev. 2 - 2
4 of 15
www.diodes.com
March 2014
© Diodes Incorporated
AP3440
A Product Line of
Diodes Incorporated
N
E
W
P
R
O
D
U
C
T
Absolute Maximum Ratings
(Note 4)
Symbol Parameter Rating Unit
V IN
VIN Pin Voltage -0.3 to 6.5 V
V EN
EN Pin Voltage -0.3 to 6.5 V
V
SW
SW Pin Voltage -0.3 to V
IN
+0.3 V
V
FB
FB Pin Voltage -0.3 to 6.5 V
V
COMP
COMP Pin Voltage -0.3 to 6.5 V
V
PGD
PGD Pin Voltage -0.3 to 6.5 V
V
RT/CLK
RT/CLK Pin Voltage -0.3 to 6.5 V
V
SS
SS Pin Voltage -0.3 to 6.5 V

JA
Thermal Resistance 70 ºC/W
T
J
Operating Junction Temperature -40 to +125 ºC
T
STG
Storage Temperature -65 to +150 ºC
T
LEAD
Lead Temperature (Soldering, 10sec) +260 ºC
—
ESD(Machine Model) 200 V
—
ESD(Human Body Model) 2000 V
Note 4: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
IN
Input Voltage 2.95 5.5 V
I
OUT(MAX)
Maximum Output Current 4 — A
T
A
Operating Ambient Temperature -40 +85 ºC
Electrical Characteristics
(@V
IN
=2.95 to 5.5V, T
A
=+25ºC, unless otherwise specified. Specifications with boldface type apply
over full operating temperature range from -40 to +85ºC.)
Symbol Parameters Conditions Min Typ Max Unit
SUPPLY VOLTAGE (VIN PIN)
V
IN
Input Voltage — 2.95 — 5.5 V
I
Q
Quiescent Current
V
FB
=0.9V, V
IN
=5V,
T
A
=+25ºC, R
T
=400k

— 360 575 μA
I
SHDN
Shutdown Supply Current
V
EN
=0V,T
A
=+25

C,
2.95V≤V
IN
≤5.5V
— 2 5 μA
ENABLE AND UVLO (EN PIN)
V
EN_H
Enable Threshold
Rising 1.16 1.25 1.37 V
V
EN_L
Falling — 1.18 — V
V
UVLO
Internal Under Voltage
Lockout Threshold
— — 2.6 2.8 V
V
HYS
Internal Under Voltage
Hysteresis
— — 150 — mV
