Absolute Maximum Ratings
(Note 4)
Symbol Parameter Rating Unit
V
DD
, V
DDP
Supply Voltage -0.3 to 6 V
V BS BOOT Pin Voltage -0.3 to V PHASE +6 V
V UGATE Voltage from UGATE to PHASE -0.3 to 6 V
V LGATE Voltage from LGATE to GND -0.3 to 6 V
V
PHASE Voltage from PHASE to GND -0.3 to 36 V
V
PGND Voltage from PGND to GND -0.3 to 0.3 V
– Voltage from Other Pins to GND -0.3 to 6 V

JA
Thermal Resistance (Junction to Ambient) 60  C/W
T
J
Operating Junction Temperature +150  C
T
STG
Storage Temperature -65 to +150  C
T
LEAD
Lead Temperature (Soldering, 10Secs) +260  C
V
HBM
ESD (Human Body Model) 2000 V
V
MM
ESD (Machine Model) 200 V
Note 4: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
DD
, V
DDP
Supply Voltage 4.5 5.5 V
V
IN
Input Voltage 4.5 26 V
V
OUT(MAX)
Maximum Output Voltage – 5.5 V
T
A
Operating Ambient Temperature -40 +85 ºC
