Absolute Maximum Ratings
(Note 5)
Symbol
Parameter
Rating
Unit
V
CC
Supply Voltage
-0.3 to 22
V
V
FB
FB Input Voltage
-1 to 10
V
V
CBO
Collector-emitter Voltage
700
V
–
Collector DC Current
AP3968/69
1.5
A
AP3970
4
T
J
Operating Junction Temperature
+150
°C
T
STG
Storage Temperature
-65 to +150
°C
T
LEAD
Lead Temperature (Soldering, 10 sec)
+300
°C
–
ESD (Machine Model)
200
V
–
ESD (Human Body Model)
2000
V
P
D
Total Power Dissipation
AP3968
0.7
W
AP3969
0.9
AP3970
1.1
Note 5
: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the
device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
CC
Supply Voltage
–
22
V
T
OP
Operating Temperature Range
-40
+85
°C
f
(MAX)
Maximum Operating Frequency
–
60
kHz
Thermal Impedance
Symbol
Parameter
Value
Unit
θ
JA
Junction to Ambient
AP3968
100
°C/W
AP3969
80
AP3970
65
θ
JC
Junction to Case
AP3968
50
AP3969
40
AP3970
35
