Package Outline Dimensions

(All dimensions in mm(inch).)

(1) Package Type: SO-7

3.800(0.150)
4.000(0.157)

1.270(0.050)

TYP

4.700(0.185)
5.100(0.201)

0.330(0.013)
0.510(0.020)

0.190(0.007)
0.250(0.010)

0.100(0.004)
0.250(0.010)

1.350(0.053)
1.750(0.069)

0.450(0.017)
0.800(0.031)

8°

0°

5.800(0.228)

6.200(0.244)

2.54(0.100)

TYP

1.250(0.049)
1.500(0.059)

Note: Eject hole, oriented hole and mold mark is optional.
