BSS123W

Document number: DS30368 Rev. 11 - 2

2 of 5

www.diodes.com

October 2013

© Diodes Incorporated

BSS123W





Maximum Ratings

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Value

Units

Drain-Source Voltage

V

DSS

100 V

Drain-Gate Voltage R

GS

 20KΩ

V

DGR

100 V

Gate-Source Voltage

Continuous

V

GSS

20

V

Drain Current (Note 6)

Continuous

Pulsed

I

D

I

DM

170
680

mA




Thermal Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Value

Units

Total Power Dissipation (Note 6)

P

D

200 mW

Thermal Resistance, Junction to Ambient (Note 6)

R

θJA

625 °C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +150

°C



Electrical Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic

Symbol

Min

Typ

Max

Unit

Test Condition

OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage

BV

DSS

100

V

V

GS

= 0V, I

D

= 250µA

Zero Gate Voltage Drain Current

I

DSS

1.0

10

µA
nA

V

DS

= 100V, V

GS

= 0V

V

DS

= 20V, V

GS

= 0V

Gate-Body Leakage, Forward

I

GSSF

50

nA

V

GS

= 20V, V

DS

= 0V

ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage

V

GS(th)

0.8

1.4

2.0

V

V

DS

= V

GS

, I

D

= 1mA

Static Drain-Source On-Resistance

R

DS(ON)



6.0

10

V

GS

= 10V, I

D

= 0.17A

V

GS

= 4.5V, I

D

= 0.17A

Forward Transconductance

g

FS

80

370

mS

V

DS

= 10V, I

D

= 0.17A, f = 1.0KHz

Drain-Source Diode Forward Voltage

V

SD

0.84 1.3 V V

GS

= 0V, I

S

= 0.34A

DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance

C

iss

29

60

pF

V

DS

= 25V, V

GS

= 0V, f = 1.0MHz

Output Capacitance

C

oss

10

15

pF

Reverse Transfer Capacitance

C

rss

2

6

pF

SWITCHING CHARACTERISTICS(Note 8)
Turn-On Rise Time

t

r

8

ns

V

DD

= 30V, I

D

= 0.28A,

R

GEN

= 50Ω, V

GS

= 10V

Turn-Off Fall Time

t

f

16

ns

Turn-On Delay Time

t

D(ON)

8

ns

Turn-Off Delay Time

t

D(OFF)

13

ns

Notes:

6. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com.
7. Short duration pulse test used to minimize self-heating effect.

8. Guaranteed by design. Not subject to production testing.
