ULN2002A/ ULN2003A/ ULN2004A
Document number: DS35313 Rev. 5 - 2
9 of 11
www.diodes.com
June 2014
© Diodes Incorporated
ADVAN
CE I
N
F
O
RM
ATI
O
N
ULN2002A/ ULN2003A/ ULN2004A
Typical Performance Characteristics
(cont.)
50 55 60 65 70 75 80 85
100
150
200
250
300
350
400
450
500
O
u
tp
u
t C
u
rr
e
n
t (m
A)
Input Current ( μ A)
Minimum
V
CE
= 2 V
T
J
= - 40 O C to 105 O C
Figure 17 Output Current vs. Input Current
Ordering Information
Part Number Package Code Packaging
13” Tape and Reel
Quantity Part Number Suffix
ULN2002AS16-13 S16 SO-16 2500/Tape & Reel -13
ULN2003AS16-13 S16 SO-16 2500/Tape & Reel -13
ULN2004AS16-13 S16 SO-16 2500/Tape & Reel -13
Marking Information
SO-16
( Top View )
1
9
8
ULN200XA
Logo
16
Part Number
WW : Week : 01~52; 52
YY : Year : 08, 09,10~
XX : Internal Code
represents 52 and 53 week
YY WW X X Device:
ULN2002A
ULN2003A
ULN2004A
