Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Static Characteristics
Drain-Source Clamp Voltage
V
DS(AZ)
60 65 70 V
I
D
= 10mA
Off State Drain Current
I
DSS
- - 1
µA
V
DS
= 12V, V
IN
= 0V
- - 2
V
DS
= 36V, V
IN
= 0V
Input Threshold Voltage
V
IN(th)
0.7 1 1.5 V
V
DS
= V
GS
, I
D
= 1mA
Input Current
I
IN
- 60 100
μA
V
IN
= +3V
- 120 200
V
IN
= +5V
Input Current while Over Temperature Active
-
-
-
400
μA
V
IN
= +5V
Static Drain-Source On-State Resistance
R
DS(on)
- 85 125
m
Ω
V
IN
= +3V, I
D
= 1A
- 75 100
V
IN
= +5V, I
D
= 1A
Continuous Drain Current (Notes 4 & 8)
I
D
2.0 -
-
A
V
IN
= 3V; T
A
= 25
°C
2.2 -
-
V
IN
= 5V; T
A
= 25
°C
Continuous Drain Current (Notes 4 & 7)
2.6 -
-
V
IN
= 3V; T
A
= 25
°C
2.8 -
-
V
IN
= 5V; T
A
= 25
°C
Current Limit (Note 10)
I
D(LIM)
4 8 -
A
V
IN
= +3V
6 13 -
V
IN
= +5V
Dynamic Characteristics
Turn On Delay Time
t
d(on)
- 8.6 -
μs
V
DD
= 12V, I
D
= 1A, V
GS
= 5V
Rise Time
t
r
- 18 -
μs
Turn Off Delay Time
t
d(off)
- 34 -
μs
Fall Time
f
f
- 15 -
μs
Over-Temperature Protection
Thermal Overload Trip Temperature (Note 11)
T
JT
150 175
-
°C
-
Thermal Hysteresis (Note 11)
f
f
- 10 -
°C
-
Notes:
10. The drain current is restricted only when the device is in saturation (see graph ‘typical output characteristic’). This allows the device to be used in the
fully on state without interference from the current limit. The device is fully protected at all drain currents, as the low power dissipation generated
outside saturation makes current limit unnecessary.
11. Over-temperature protection is designed to prevent device destruction under fault conditions. Fault conditions are considered as “outside” normal
operating range, so this part is not designed to withstand over-temperature for extended periods..
