ZXMN6A25N8
60V SO8 N-channel enhancement mode MOSFET
Summary
Description
This new generation Trench MOSFET from
Zetex features low on-resistance and fast switching,
making it ideal for high efficiency power management applications.
Features
•
Low on-resistance
•
Fast switching speed
•
Low gate drive
•
SO8 package
Applications
•
DC-DC Converters
•
Power management functions
•
Disconnect switches
•
Motor control
Ordering information
Device marking
ZXMN6A25
V
(BR)DSS
R
DS(on)
(Ω) I
D
(A)
0.050
@
V
GS
=10V 7.0
60
0.070
@
V
GS
=4.5V
Device Reel
size
(inches)
Tape width
(mm)
Quantity
per reel
ZXMN6A25N8TA 7
12 500
D
S
G
D
S
S
S
G
Top view
D
D
D
