32
APPENDIx
A. NYX-7 PRO LIST OF SPARE PARTS
The parts authorized in this list of spare parts are required for operator maintenance. This list includes
parts that must be removed in order to replace authorized parts.
The ITEM NO. Column indicates the number used to identify items in Figure A-1.
The PART NO. Column indicates the primary number used by the manufacturer to identify an item; this
number controls the design and characteristics of the item by means of its engineering, specifications,
standards, and inspection requirements.
FIGURE A-1. NYX-7 PRO SPARE PARTS
11 12
13 10
6
4
2
7
9
1
5
6
5
8
