6
LIST OF TABLES
TABLE TITLE PAGE
2-1 PVS-7 System Description 12
2-2 PVS-7 Optional Equipment 12
2-3 Operator Adjustment Limits 13
2-4 Electrical Data 13
2-5 Mechanical Data 13
2-6 Optical Data 13
2-7 Environmental Data 14
2-8 Consumable Items 15
3-1 Controls and Indicators 17
3-2 Preventive Maintenance Checks and Services 18
3-3 Estimated Battery Life 21
4-1 Operator’s Troubleshooting 33
A-1 PVS-7 List of Spare Parts 39
HOW TO USE THIS MANUAL
USAGE
You must familiarize yourself with the entire manual before operating the equipment. Before perform-
ing any kind of maintenance on your device, read the section on maintenance in its entirety. Follow all
WARNINGS, CAUTIONS, and NOTES.
MANUAL OVERVIEW
This manual contains sections on Operating and Maintaining the PVS-7 Night Vision Goggles.
The list of Spare Parts can be found in Appendix A.
The Product Warranty Registration Card can be found in Appendix B.
