OPERATING INSTRUCTIONS
3.1 OPERATING PROCEDURES
3.1.1 GENERAL
This section contains instructions for operating the PVS-7 under normal conditions. Explanations of
control functions and indicators are provided.
CAUTION:
The PVS-7 is a precision electro-optical instrument and must be handled carefully at all times.
3.1.2 CONTROLS AND INDICATORS
The PVS-7 is adjustable to accommodate different users and corrects for most differences in eyesight.
The controls and indicators for the PVS-7 are shown or described in Figure 3-1 and Table 3-1.
1
2
3
4
5 6
7
10
11 12
FIGURE 3-1. PVS-7 CONTROLS
