ASUS P4B533-E motherboard user guide 2-17
2. CPU Core:Bus frequency multiple (DSW2 Switches 1-4)
This option sets the frequency multiple between the CPU internal and
external frequencies. This must be set in conjunction with the CPU Bus
Frequency.
Make sure that the JEN jumper is set to jumper mode before setting
the above switches.
The option to set the CPU core:bus frequency multiple is available only
on unlocked CPUs. If you are using a locked CPU, setting the switches
does not produce any effect.
P4B533-E
®
P4B533-E CPU Frequency
Multiple Selection
DSW2
ON
1 2 3 4
24.0x
ON
1 2 3 4
23.0x
ON
1 2 3 4
22.0x
ON
1 2 3 4
21.0x
ON
1 2 3 4
17.0x
ON
1 2 3 4
18.0x
ON
1 2 3 4
19.0x
ON
1 2 3 4
20.0x
ON
1 2 3 4
16.0x
ON
1 2 3 4
15.0x
ON
1 2 3 4
14.0x
ON
1 2 3 4
13.0x
ON
1 2 3 4
8.0x
ON
1 2 3 4
10.0x
ON
1 2 3 4
11.0x
ON
1 2 3 4
12.0x
3. CPU external frequency selection (DSW1 Switches 1-6)
This option tells the clock generator what frequency to send the CPU.
This allows the selection of the CPU’s external frequency (or Bus
Clock). The BUS Clock multiplied by the Frequency Multiple equals the
CPU’s internal frequency (the advertised CPU speed).
To select the CPU external frequency using the DIP switches, ensure
that the JEN jumper is set to jumper mode.
P4B533-E
®
DSW1
P4B533-E CPU
External Frequency Selection
CPU
AGP
PCI 100MHz
66MHz
33MHz
ON 123
4
5
6
105MHz
70MHz
35MHz
ON 123
4
5
6
109MHz
72MHz
36MHz
ON 123
4
5
6
133MHz
66MHz
33MHz
ON 123
4
5
6
141MHz
70MHz
35MHz
ON 123
4
5
6
CPU
AGP
PCI 145MHz
72MHz
36MHz
ON 123
4
5
6
166MHz
66MHz
33MHz
ON 123
4
5
6
200MHz
66MHz
33MHz
ON 123
4
5
6
