xi
P4B533-E specifications summary
CPU
Chipset
Front Side Bus (FSB)
Memory
Expansion slots
IDE
Audio (optional)
LAN (optional)
IEEE 1394 (optional)
Special features
Rear panel I/O
Socket 478 for Intel ® Pentium ® 4
On-die 512KB/256KB L2 cache
Intel 82845E MCH
Intel 82801 DB ICH4
533/400 MHz
3 x 184-pin DDR DIMM sockets for up to 2GB memory
Supports PC2100/PC1600 unbuffered ECC/non-ECC DDR
DIMMs
1 x AGP Pro (1.5V only)
6 x PCI
2 x UltraDMA 100/66/33
2 x ATA133 for RAID 0/1 (optional)
C-Media 8738-MX 6-channel PCI audio controller
Intel 82562ET PHY
NEC 1394 controller
2 x 1394 ports
ASUS JumperFree™ mode
ASUS POST Reporter™
ASUS EZ Plug™
ASUS MyLogo2
ASUS Q-Fan
ASUS EZ Flash
Power Loss Restart
STR (Suspend-to-RAM)
SFS (Stepless Frequency Selection)
Adjustable CPU V
CORE
, and memory and AGP voltages
Multi-language BIOS
AGP warning LED
1 x Parallel port
2 x Serial ports
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0/USB 1.1 ports
Line In/Line Out/Microphone ports (optional)
(continued on the next page)
