1-6 Chapter 1: Product introduction
1.4 Motherboard overview
Before you install the P4B533-E motherboard, familiarize yourself with its
physical configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.
1.4.1 Major components
The following are the major components of the P4B533-E motherboard as
pointed out in the picture on page 1-7.
1. ATX 12V connector
2. CPU socket
3. North Bridge controller
4. DDR DIMM sockets
5. ATX power connector
6. AGP warning LED
7. ASUS EZ Plug™ +12V connector
8. Floppy connector
9. IDE connectors
10. DIP switches (DSW1)
11. ASUS ASIC
12. Super I/O controller
13. RAID Ultra ATA/133/100 connectors
(optional)
14. South Bridge controller
15. RAID controller (optional)
16. Flash EEPROM
17. DIP switches (DSW2)
18. Standby power LED
19. IEEE 1394 controller (optional)
20. PCI slots
21. Audio controller (optional)
22. AGP PRO slot
23. LAN PHY (optional)
24. PS/2 mouse port
25. Parallel port
26. RJ-45 port (optional)
27. Line In jack (optional)
28. Line Out jack (optional)
29. Microphone jack (optional)
30. USB 2.0 ports 1 and 2
31. Serial ports
32. USB 2.0 ports 3 and 4
33. Keyboard port
See page 1-8 for the specifications of each component. Refer to
Chapter 2 for detailed information on the components.
