1-12

Chapter 1: Product introduction

Q87T

Q87T Display panel backlight power selection

1

2

2

3

12V

(Default)

19V

BLKT_PWR_SEL

Q87T

Q87T LVDS or eDP selection

1

2

2

3

for LVDS

for eDP

(Default)

FPD_SEL

Q87T

Q87T Display panel VCC power

1

3V

(Default)

2

5V

3

12V

VCC_PWR_SEL

4.

Display panel backlight power selector (BLKT_PWR_SEL)

Pins

Setting

1-2

12V

2-3

19V

6.

Display panel VCC power selector (VCC_PWR_SEL)

Pins

Setting

1

3V

2

5V

3

12V

5. LVDS panel or eDP selector (3-pin FPD_SEL)

Pins

Setting

1-2

LVDS (Default)

2-3

eDP
