ASUS P8H67-M EVO 3-19
Chapter 3
3.5.7 Onboard Devices Configuration
Scroll down to display the following items:
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
> Serial Port Configuration
HD Audio Controller [Enabled]
[Enabled] Enables the High Definition Audio Controller.
[Disabled] Disables the controller.
The following two items appear only when you set the HD Audio Controller item to
[Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD]
Sets the front panel audio connector (AAFP) mode to high definition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Enabled/Disabled Marvell Storage
OPROM.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
Back Advanced\ Onboard Devices Configuration >
EFI BIOS Utility - Advanced Mode
HD Audio Controller Enabled
Front Panel Type HD
SPDIF Out Type SPDIF
VIA 1394 Controller Enabled
PCI Express X16_2 slot (black) bandwidth Auto
Marvell Storage Controller Enabled
Marvell Storage OPROM Enabled
Realtek LAN Controller Enabled
Realtek PXE OPROM Disabled
Asmedia USB 3.0 Controller Enabled
Asmedia USB 3.0 Battery Charing Support Enabled
