P8H67-M EVO specifications summary
CPU LGA1155 socket for Intel ® 2nd Generation Core™ i7 / Core™ i5 /
Core™ i3 processors
Supports 32nm CPU
Supports Intel ® Turbo Boost Technology 2.0*
* The Intel Turbo Boost Technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel CPU support list
Chipset Intel ® H67 Epress Chipset
Memory 4 DIMM, ma. 32GB*, DDR3 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual channel memory architecture
Supports Intel ® Extreme Memory Profile (XMP)
* The ma. 32GB memory capacity can be supported with DIMMs
of 8GB (or above). ASUS will update QVL once the DIMMs are
available on the market.
** Hyper DIMM support is subject to the physical characteristics
of individual CPUs. Some hyper DIMMs only support one
DIMM per channel. Please refer to Memory QVL for details.
*** Refer to www.asus.com or this user manual for the Memory
QVL (Qualified Vendors Lists)
Expansion Slots 1 x PCI Express 2.0 x16 slot [blue] (at x16 mode)
1 x PCI Express 2.0 x16 slot [black] (at x4 mode, compatible with
PCIe x1, x2 and x4 devices)
1 PCI Epress 2.0 1 slot
1 PCI slot
VGA Multi-VGA output support: DisplayPort, HDMI, DVI-D, and RGB
ports
Supports DisplayPort with ma. resolution 2560 1600 @60Hz
Supports HDMI with ma. resolution 1920 1200 @60Hz
Supports DVI with max. resolution 1920 x 1200 @60Hz
Supports RGB with ma. resolution 2048 1536 @75Hz
Maimum shared memory of 1748MB
Multi-GPU support Supports ATI ® Quad-GPU CrossFireX™ Technology
Storage Intel ® H67 Express Chipset:
- 2 x SATA 6.0 Gb/s ports (gray)
- 4 x SATA 3.0 Gb/s ports (blue)
- Intel Rapid Storage Technology supports RAID 0, 1, 5 and 10
Marvell
® 88SE6111 SATA & PATA controller:
- 1 x Ultra DMA 133/100/66 for up to 2 PATA devices
- 1 x eSATA 3Gb/s port (SATA on-the-go)
LAN Realtek ® 8111E Gigabit LAN controller
IEEE 1394 VIA ® 6315N controller supports 2 x IEEE 1394a ports (one at mid-
board, one at back panel)
USB ASMedia USB 3.0 controller:
- 2 x USB 3.0 ports at back panel (blue)
Intel
® H67 Express Chipset:
- 12 x USB 2.0 ports (8 ports at mid-board, 4 ports at back
panel)
(continued on the next page)
