xii
*Specifications are subject to change without notice.
P8H67-M EVO specifications summary
Back Panel I/O Ports 1 x PS/2 Keyboard/Mouse port
1 x Optical S/PDIF Out
1 x DVI-D Output
1 x HDMI Output
1 x D-Sub Output
1 x Display Port Output
1 x Power eSATA port
1 x IEEE 1394a port
1 x RJ45 port
2 x USB 3.0/2.0 ports (blue)
4 x USB 2.0/1.1 ports
8-channel Audio I/O
Internal I/O Connectors 4 x USB 2.0/1.1 connectors support additional 8 USB ports
2 x SATA 6.0Gb/s connectors (gray)
4 x SATA 3.0Gb/s connectors (blue)
1 x IDE connector
1 x 4-pin CPU Fan connector
1 x 4-pin Chassis Fan connector
1 x 3-pin Power Fan connector
1 x IEEE1394a connector
1 x Front panel audio connector
1 x S/PDIF Out Header
1 x 24-pin ATX Power connector
1 x 8-pin EATX 12V Power connector
1 x System Panel (Q-Connector)
1 x MemOK! button
1 x GPU Boost switch
1 x EPU switch
1 x COM port connector
1 x Clear CMOS jumper
1 x TPM header
BIOS Features 32 Mb Flash ROM, EFI MIOS, PnP, DMI 2.0, WfM 2.0,
SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS,
ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Support DVD Contents Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
Form Factor uATX Form Factor, 9.6”x 9.6” (24.5cm x 24.5cm)
