ASUS P8H67-M EVO 3-13
Chapter 3
3.5.2 CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically
detects.
The items shown in this screen may be different due to the CPU you installed.
Scroll down to display the following items:
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Allows user can manually adjust the
maximum non-turbo CPU ration. The
value will be limit to CPU base or
factory setting.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
Back Advanced\ CPU Configuration >
EFI BIOS Utility - Advanced Mode
CPU Configuration
Genuine Intel(R) CPU 0 @ 3.00GHz
EM64T Supported
Processor Speed 3000 MHz
Processor Stepping 206a3
Microcode Revision Not loaded
L1 Cache 128 kb
L2 Cache 1024 kb
L3 Cache 6144 kb
Processor Cores 4
Intel HT Technology Supported
CPU Ratio Range 16-30
CPU Current Ratio 30
CPU Ratio Auto
Intel Adaptive Thermal Monitor Enabled
Hyper-threading Enabled
Active Processor Cores All
Limit CPUID Maximum Disabled
Execute Disable Bit Enabled
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Intel Virtualization Technology Disabled
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
CPU C1E Enabled
CPU C3 Report Enabled
CPU C6 Report Enabled
CPU Ratio [Auto]
Allows you to set the ratio between the CPU Core Clock and the BCLK Frequency. Use <+>
and <-> keys to adjust the ratio. The valid value ranges vary according to your CPU model.
Intel Adaptive Thermal Monitor [Enabled]
[Enabled] Enables the overheated CPU to throttle its clock speed to cool down.
[Disabled] Disables the CPU thermal monitor function.
