Asus P8H67-M EVO - Manual (Page 55)

ASUS P8H67-M EVO 2-39
Chapter 2
2.3.10 Rear panel connection
Rear panel connectors
1. PS/2 keyboard/mouse combo port 8. IEEE 1394a port
2. USB 2.0 ports 3 and 4 9. DisplayPort output port**
3. Optical S/PDIF Out port 10. HDMI out port**
4. VGA out port 11. DVI out pot
5. LAN (RJ-45) port* 12. USB 3.0 ports 1 and 2
6. USB 2.0 ports 5 and 6 13. Audio I/O ports***
7. Power External SATA port
*and **: Refer to the tables on the next page for LAN port and audio port definitions.
