3-26 Chapter 3: BIOS setup
Chapter 3
3.6.3 Onboard Devices Configuration
Onboard Devices Configuration
Serial Port1 Address [3F8/IRQ4]
HDAudio Controller [Enabled]
Front Panel Select [HD Audio]
Onboard LAN Controller [Enabled]
Onboard LAN Boot ROM [Disabled]
VT6330 1394/IDE Controller [Enabled]
VT6330 IDE Boot ROM [Enabled]
USB3.0 Controller [Enabled]
M5A88-V EVO BIOS Setup Version 0207
Advanced
Allows BIOS to select
Serial Port1 Base
Addresses.
SidePort Clock Speed [DDR3-1333MHz]
This item appears only when you set the Internal Graphics Mode item to [SIDEPORT]
or [UMA+SIDEPORT]. Configuration options: [DDR3-1333MHz] [DDR3-1400MHz]
[DDR3-1430MHz] [DDR3-1460MHz] ~ [DDR3-2000MHz]
UMA-SP Interleave Mode [Auto]
This item appears only when you set the Internal Graphics Mode item to [UMA+SIDEPORT].
Configuration options: [Auto] [Coarse] [Fine]
Surround View [Auto]
If you set the PCI Express device as the primary display and enable this item, you may use
the internal graphics as the secondary display. This item appears only when you set the
Internal Graphics Mode item to [UMA], [SIDEPORT], or [UMA+SIDEPORT].
Configuration options: [Auto] [Enabled] [Disabled]
When set to [Auto], only the primary display could be activated.
Frame Buffer Location [Above 4G]
Allows you to select the FB Location. Configuration options: [Below 4G] [Above 4G]
AMD HDMI Audio [Enabled]
Allows you to disable or enable the AMD 880 HD Audio.
Configuration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
HDAudio Controller [Enabled]
Allows you to enable or disable the HD Audio controller.
Configuration options: [Disabled] [Enabled]
