ASUS M5A88-V EVO 2-3
Chapter 2
2.2.2 Layout contents
Connectors/Jumpers/Slots Page
1. CPU, chassis, and power fan connectors (4-pin CPU_FAN, 3-pin CHA_FAN,
3-pin PWR_FAN)
2-30
2. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-32
3. AM3+ CPU Socket 2-5
4. DDR3 DIMM slots 2-10
5. Core Unlocker LED (02LED1) 2-36
6. TPU LED (02LED2) 2-36
7. TPU switch (TPU) 2-19
8. Core Unlocker switch (CORE_UNLOCKER) 2-18
9. MemOK! switch 2-20
10. DRAM LED (DRAM_LED) 2-35
11. AMD ® SB850 Serial ATA 6.0 Gb/s connectors (7-pin SATA1, SATA2, SATA3,
SATA5, SATA6)
2-27
12. IDE connector (40-1 pin PRI_EIDE) 2-26
13. Clear RTC RAM (3-pin CLRTC) 2-17
14. Standby power LED (SB_PWR) 2-35
15. System panel connector (20-8 pin PANEL) 2-33
16. IEEE 1394a port connector (10-1 pin IE1394_1) 2-28
17. USB connectors (10-1 pin USB78, USB910, USB1112, USB1314) 2-29
18. Serial port connector (10-1 pin COM1) 2-28
19. Digital audio connector (4-1 pin SPDIF_OUT) 2-31
20. Front panel audio connector (10-1 pin AAFP) 2-31
