ASUS P/I-AP6N User’s Manual 11
III. INSTALLATION
Jumpers
1) BBLKW p. 13 Flash ROM Boot Block Program (Enable/Disable)
2) RTCLR p. 14 Real Time Clock RAM (Operation/Clear CMOS Data)
3) AUDIO_JP p. 15 Audio Selection (Enabled/Disabled)
4) FS0, FS1 p. 16 CPU External Clock (BUS) Frequency Selection
5) BF0, BF1, BF2, BF3 p. 16 CPU:BUS Frequency Ratio
6) VID0 - VID3 p. 17 Voltage Regulator Output Selection
Expansion Slots
1) SIMM Sockets p. 18 DRAM Memory Expansion Sockets
2) CPU ZIF Socket 8 p. 21 Central Processing Unit (CPU) Socket
3) Riser Slot p. 22 Slot for a Riser Expansion Slot Card
Connectors
1) PS2KB p. 24 PS/2 Keyboard Connector (6-pin Female)
2) PS2MOUSE p. 24 PS/2 Mouse Connector (6-pin Female)
3) COM1, COM2 p. 24 Serial Port COM1 & COM2 (9-pin Male)
4) PRINTER p. 25 Parallel (Printer) Port Connector (25-pin Female)
5) Video Monitor Output p. 25 Video Connector for Video Monitor (15-pin Female)
6) FLOPPY p. 25 Floppy Drive Connector (34-pin Block)
7) IDE1, IDE2 p. 26 Primary / Secondary IDE Connector (40-pin Blocks)
8) IDELED p. 26 IDE LED Activity Light
9) TB LED (PANEL) p. 27 Turbo LED/Power LED (2-pins)
10) SMI (PANEL) p. 27 SMI Switch Lead (2-pins)
11) RESET (PANEL) p. 27 Reset Switch Lead (2-pins)
12) KEYLOCK (PANEL) p. 27 Keyboard Lock Switch Lead (5-pins)
13) SPEAKER (PANEL) p. 27 Speaker Connector (4-pins)
14) IR p. 28 Infrared Port Module Connector
15) VOL_CON p. 28 Digital Volume Control (Up/Down)
16) FANPWR1, 2, 3 p. 29 1 CPU, 2 Power Supply, 3 Chassis Fan Power Leads (6-pin Block)
17) CHASSIS p. 29 Chassis Open Alarm Lead (3-pin Block)
18) Power Input p. 30 Motherboard Power Connector (12-pin Block)
(Map of Board)
