34 Chapter 2: Basic Installation
5. Connect a power cable from
the power supply to the power
connector at the back of the
HDD. Use the cable with the
white connector labeled P3.
6. Connect one end of the IDE
hard disk ribbon cable to the
IDE interface at the back of
the HDD, matching the red
stripe on the cable with Pin 1
on the IDE interface.
Red stripe to Pin 1
IDE ribbon cable Power cable (P3)
7. Connect the other end of the
IDE ribbon cable to the
primary IDE connector (blue
connector labeled PRI_IDE1)
on the motherboard.
Primary IDE connector
(PRI_IDE1)
