Page 19

Get started!

1-15

NOTE

A CF card fits only in one orientation, and slides smoothly into
the slot if inserted correctly. DO NOT force the CF card into
the slot!

Label side

Installing and removing a CF card

To install a CF card:

1. Locate the card side with the 50-pin female connector and insert into

the slot. The label side (usually the side with the card manufacturer’s
name) face up, and the bar code/serial number side face down.

2. Push the card all the way into the slot until it fits completely. If properly

installed, the CF card edge aligns with the top edge of the device.
