Asus Striker User Manual
Page 59
ASUS Striker
2-35
9. S/PDIF output connector (4-1 pin SPDIF_02)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF)
port(s). Connect the S/PDIF module cable to this connector, then install the
module to a slot opening at the back of the system chassis.
The S/PDIF module is purchased separately.
STRIKER
®
STRIKER SPDIF OUT connector
+5V
SPDIFOUT
GN
D
SPDIF_O2
