ASUS RS100-E4/PI2 5-31
CPU Target Temperature [XXX]
MB1 Target Temperature [XXX]
Displays the detected CPU and system threshold temperature when the
Smart Fan Control is enabled.
VCORE1 Voltage, VCORE2 Voltage, 3.3V Voltage, 5V
Voltage, 5VSB Voltage, VBAT Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage outputs
through the onboard voltage regulators.
5.6 Boot menu
The Boot menu items allow you to change the system boot options. Select
an item then press to display the sub-menu.
Boot Settings
Boot Device Priority
Hard Disk Drives
Boot Settings Configuration
Security
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Specifies the Boot
Device Priority
sequence.
A virtual floppy disk
drive (Floppy Drive
B:) may appear when
you set the CD-ROM
drive as the first boot
device.
BIOS SETUP UTILITY
Main Advanced Power Boot Exit
