ASUS RS100-E4/PI2 1-3
1.2 System specifications
The ASUS RS100-E4/PI2 is a 1U barebone server system featuring the
ASUS P5M2-M/RS100-E4 motherboard. The server supports LGA775 Intel ®
Xeon ® 3000 series processors plus other latest technologies through the
chipsets onboard.
Chassis Rackmount 1U (R09)
Motherboard ASUS P5M2-M/RS100-E4
Chipset NorthBridge: Intel ® Xeon 3000 chipset (Mukilteo-2)
SouthBridge: Intel ® ICH7R
CPU LGA775 socket for Intel ® Xeon ® 3000 series processors
Supports Intel ® Enhanced Memory 64 Technology (EM64T)
Supports Enhanced Intel SpeedStep ® Technology (EIST)
Memory Dual-channel memory architecture
4 x 240-pin DIMM sockets support unbuffered
ECC/non-ECC DDR2-533/667 memory modules
Supports up to 8 GB system memory
LAN Dual embedded Broadcom BCM5721 Gigabit LAN controllers that
comply with PCI Express 1.0a specifications
VGA Volari ® XGI Z7 PCI-based VGA controller with 32 MB memory
Storage Intel ® ICH7R Southbridge supports:
- 2 x SATAII drives with RAID functionality or
IAA(RAID 0, RAID 1), or LSI (RAID 0, RAID 1)
Expansion slots 1 x PCI-E2 X8 slot (x8 link) (on a riser card)
1 x SO-DIMM socket for ASUS Server Management Board
Front panel 1 x Optical drive (optional)
2 x USB 2.0 ports
Power switch
Reset switch
LEDs: Power, HDD access, LAN 1, LAN 2
HDD LEDs: Status, activity
Rear panel 1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
2 x USB 2.0 ports
1 x Parallel port
1 x Serial port (COM1)
1 x VGA port
2 x LAN (RJ-45) ports
Management ASUS Server Web-based Management (ASWM 2.0)
Hardware
support (optional)
SM-Bus, ASMB3-SOL support IPMI 2.0 Over LAN management
card
Hardware
monitors
Voltage, temperature, and fan speed monitoring
Automatic System Restart (ASR) feature
Power supply 300W single power supply, 100V~240V, 50Hz~60Hz
Dimensions 381 mm (l) x 430 mm (w) x 43.6 mm (h)
Net Weight 6.5 kg
