2-17

ASUS RS100-E4/PI2

2.5.3 Installing optical disk drive (ODD)

To install ODD:

1. Connect the 80-pin IDE cable blue

connector to the IDE connector

onboard.

5. Connect the other end of the Serial ATA signal connector to the onboard SATA

connector labeled SATA3.

P5M2-M/RS100-E

4

®

P5M2-M/RS100-E4 SATA3 connector

SATA3

G

ND

RS

AT

A_

TX

P3

RS

AT

A_

TX

N3

G

ND

RS

AT

A_

RX

P3

RS

AT

A_

RX

N3

G

ND

2. Align the bundled optical disk drive*

(ODD) into the drive slot as shown.

Optical disk drive slot

Optical disk drive (*optional)

ODD bracket
