5-24 Chapter 5: BIOS setup
DRAM Frequency [Auto]
Allows you to set the DDR operating frequency.
Configuration options: [Auto] [533 MHz] [667 MHz]
Configure DRAM Timing by SPD [Enabled]
When this item is enabled, the DRAM timing parameters are set according
to the DRAM SPD (Serial Presence Detect). When disabled, you can
manually set the DRAM timing parameters through the DRAM sub-items.
The following sub-items appear when this item is disabled.
Configuration options: [Disabled] [Enabled]
DRAM CAS# Latency [5 Clocks]
Controls the latency between the SDRAM read command and the time
the data actually becomes available. Configuration options: [5 Clocks]
[4 Clocks] [3 Clocks] [6 Clocks]
DRAM RAS# to CAS# Delay [4 Clocks]
Controls the latency between the DDR SDRAM active command and
the read/write command. Configuration options: [2 Clocks]
[3 Clocks] [4 Clocks] [5 Clocks]
DRAM RAS# Activate to Precharge Delay [15 DRAM Clocks]
Configuration options: [1 Clocks] [2 Clocks] ~ [15 Clocks]
DRAM Write Recovery Time [4 Clocks]
Configuration options: [2 Clocks] [3 Clocks] [4 Clocks] [5 Clocks]
5.4.6 Chipset Configuration
The Chipset Configuration menu allows you to change the advanced chipset
settings. Select an item then press to display the sub-menu.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Manual DRAM Frequency
Setting or Auto by SPD
Advanced Chipset Settings
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
Spread Spectrum [Disabled]
Onboard LAN Boot ROM [Enabled]
PEG Port Configuration
PEG Port [Enabled]
PEG Port VC1 Map [TC7]
PEG Force x1 [Disabled]
Memory Remap Feature [Enabled]
