ASUS KFN4-DRE 4-29
Resume By PME# [Disabled]
When set to [Enabled], the system enables the PME to generate a wake
event while the computer is in Soft-off mode.
Configuration options: [Disabled] [Enabled]
Resume by RTC [Disabled]
Allows you to enable or disable RTC to generate a wake event. When this
item is set to [Enabled], the items RTC Alarm Date, RTC Alarm Hour, RTC
Alarm Minute, and RTC Alarm Second appear with set values.
Configuration options: [Disabled] [Enabled]
4.4.8 Hardware Monitor
V00.00 (C)Copyright 1985-2004, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Hardware Monitor
CPU1 Temperature [38ºC/100ºF]
CPU2 Temperature [N/A]
MB Temperature [34ºC/93ºF]
Front1 Fan Speed [N/A]
Front2 Fan Speed [N/A]
Front3 Fan Speed [N/A]
Front4 Fan Speed [N/A]
Front5 Fan Speed [2518RPM]
Front6 Fan Speed [N/A]
REAR1 Fan Speed [N/A]
REAR2 Fan Speed [N/A]
REAR3 Fan Speed [N/A]
REAR4 Fan Speed [N/A]
Smart Fan Control [Smart Fan II]
CPU1 Temperature [060]
CPU2 Temperature [060]
Front1 Temperature [050]
→← Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
CPU1/CPU2 Temperature [xxxºC/xxxºF]
MB Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures. Select [Ignored] if you do not wish to
display the detected temperatures. The CPU2 Temperature shows N/A if
no processor is installed in CPU 2 socket.
Front1/2/3/4/5/6 Fan Speed [xxxxRPM] or [N/A]
Rear1/2/3/4 Fan Speed [xxxxRPM] or [N/A]
The onboard hardware monitor automatically detects and displays the
front and rear fan speed in rotations per minute (RPM). If the fan is not
connected to the motherboard, the field shows N/A.
Smart Fan Control [Smart Fan II]
Allows you to enable or disable the ASUS Smart Fan feature that smartly
adjusts the fan speeds for more efficient system operation. Configuration
options: [Disabled] [Smart Fan] [Smart Fan II]
