ASUS M4A89GTD PRO Series
2-3
Chapter 2
2.2.2
Layout contents
Connectors/Jumpers/Slots
Page
1.
ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
2-36
2.
AM3 CPU Socket
2-5
3.
CPU, chassis, and power fan connectors (4-pin CPU_FAN,
4-pin CHA_FAN1, 3-pin CHA_FAN2, 3-pin PWR_FAN)
2-34
4.
DDR3 DIMM slots
2-10
5.
Core Unlocker switch (CORE_UNLOCKER)
2-24
6.
Turbo Key II switch (TURBO_KEY_II)
2-23
7.
MemOK! switch
2-22
8.
Serial port connector (10-1 pin COM1)
2-32
9.
IDE connector (40-1 pin PRI_EIDE)
2-30
10.
Standby power LED (SB_PWR)
2-39
11.
AMD
®
SB850 Serial ATA 6.0 Gb/s connectors (7-pin SATA1–6)
2-31
12.
System panel connector (20-8 pin PANEL)
2-37
13.
Clear RTC RAM (3-pin CLRTC)
2-21
14.
USB connectors (10-1 pin USB78, USB910, USB1112, USB1314)
2-33
15.
Digital audio connector (4-1 pin SPDIF_OUT)
2-35
16.
IEEE 1394a port connector (10-1 pin IE1394_2)
2-32
17.
Front panel audio connector (10-1 pin AAFP)
2-35
