5-28 Chapter 5: BIOS setup
5.6.3 Hardware Monitor
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2007, American Megatrends, Inc.
CPU Temperature
CPU Temperature [42..5ºC/108.5ºF]
MB Temperature [35ºC/95ºF]
CPU Fan1 [12300RPM]
CPU Fan2 [12134RPM]
CPU Fan3 [12356RPM]
CPU Fan4 [12646RPM]
Chassis Fan [12558RPM]
Smart Fan Control [Enabled]
VCORE Voltage [ 1.208V]
3.3V Voltage [ 3.264V]
5V Voltage [ 5.068V]
12V Voltage [11.932V]
VBAT Voltage [ 3.088V]
BIOS SETUP UTILITY
Power
CPU Temperature [xxxºC/xxxºF]
MB Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the motherboard
and CPU temperatures. Select [Disabled] if you do not wish to display the detected
temperatures.
CPU Fan1/2/3/4; Chassis Fan [xxxxRPM] or [N/A]
The onboard hardware monitor automatically detects and displays the system and
CPU fan speeds in rotations per minute (RPM). If a fan is not connected to the
connector on the motherboard, the field shows [N/A].
Smart Fan Control [Enabled]
Allows you to enable or disable the ASUS Smart Fan Control feature that smartly
adjusts the fan speeds for more efficient system operation.
Configuration options: [Disabled] [Enabled]
VCORE, 3.3V, 5V, 12V, VBAT Voltage
The onboard hardware monitor automatically detects the voltage outputs through
the onboard voltage regulators.
