Chapter 1: Motherboard Information
1.4
Motherboard layout
21.9cm (8.6in)
30.5cm (12.0in)
PWRFAN1
IR
PRIMAR
Y
IDE
P4SE
®
CR2032 3V
Lithium Cell
CMOS Power
CD1
AUX1
MODEM1
IAPANEL1
IDELED1
Accelerated Graphics Port
AGP
ALOUT1
GAME_AUDIO
Mic
In
Line
Out
Line
In
PANEL1
SMARTCON1
Super
I/O
DSW1
2Mbit
Firmware
Hub
Socket 478
USBV1
KBPWR
USBV3
DDR DIMM1 (64/72 bit, 184-pin module)
0 1
DDR DIMM3 (64/72 bit, 184-pin module)
4 5
DDR DIMM2 (64/72 bit, 184-pin module)
2 3
USB2
P
ARALLEL
PORT
COM1
COM2
CPUFAN1
PCI5
PCI6
PCI4
PCI3
PCI2
PCI1
ATX Power Connector
USB1
USB2
VEN1
SECONDAR
Y
IDE
LED1
USB3
USBV2
SMB1
CLRCMOS1
JEN1
PS/2KBMS
T: Mouse
B: Keyboard
AUX12V1
DDRVOL1
ATX12V1
FLOPPY1
ASUS
ASIC
with
Hardware
Monitor
SiS645
HOST/
Memory
Controller
SiS961B
MuTLOL
Media
I/O
PWRTMP1
CHASFAN1
SPDIF_OUT1
CHASSIS1
C-Media
4CH
The audio feature is optional.The components are grayed out in the
above motherboard layout.
