A.1 lan port for server management – Asus ASMB3-iKVM User Manual
Page 60

A-2
Appendix: Reference information
A.1
LAN port for server management
The ASUS server motherboards that support the ASMB3-IKVM comes with an
IKVM LAN port. You must use the IKVM LAN port for server management to
connect the remote server to the local/central host (direct LAN connection) or to
the network hub or router.
Refer to the illustrations below to identify the IKVM LAN port for server
management on some server motherboards.
P5BV-M/RS100-E5 motherboard
You can refer to motherboard manual for the location of IKVM LAN port.
1
8
5
6
4
2
7
3
