ASUS ASMB3-IKVM 2-3
4. Press the board firmly until the
BMC socket retaining clips snap
back and secure the board in
place.
When installed, the board appears
as shown.
5. Reinstall the remote server system cover, then connect the power plug to a
grounded wall socket.
Everytime after the AC power is re-plugged, you have to wait for about 30
seconds for the system power up.
6. Insert the LAN cable plug to the IKVM LAN port for server management.
Refer to the Appendix for the location of the IKVM LAN port for server
management on various server motherboards.
7. For direct LAN configuration, connect the other end of the LAN cable to the
local/central server LAN port.
For connection to a network hub or router, connect the other end of the LAN
cable to the network hub or router.
