6 network setup, Network setup -5 – Asus ASMB3-iKVM User Manual
Page 15
ASUS ASMB3-IKVM
1-5
1.6
Network setup
The ASMB3-IKVM server management board installed on the remote server
connects to a local/central server via direct LAN connection or through a network
hub. Below are the supported server management configurations.
Remote server
with ASMB3-IKVM
Hub or router
Direct LAN connection
LAN connection through a network hub
Remote server
with ASMB3-IKVM
RJ-45 cable
Remote console with
JAVA-based web browser
Remote console with
JAVA-based web browser
