DSL-N13 Wireless ADSL 2/2+ Modem Router User Manual
46
DSL-N13 offers two USB2.0 ports for setting up FTP server and sharing USB printer.
FTP server function
Before setup, you need to prepare a USB disk for FTP storage.
Setting up FTP server
To setup FTP server:
1. Plug your USB storage into the USB2.0 port on the DSL-N13 rear panel. Then click
USB Application -> FTP Server in the left side menu to open the configuration page.
USB applications
2. Set Enable FTP Server to Yes.
3. Allow Anonymous User to Login: If you want to allow anonymous user to access
your FTP site, select Yes; if you want to protect your data from unauthenticated
user, select No.
4. Allow Super User to Login: Select Yes to allow super user to access the FTP
server.
5. FTP Port: Set up the port number of the FTP server. For example, if the port number
is set to 1111, you can access the FTP server by typing ftp://12.168.1.1:1111 into the
address box of your Web browser (192.168.1.1 is the default IP address of DSL-N13).
6. Maximum User Allowed to Login: set up the maximum login user according to
your working environment.
7. Login Timeout in Seconds: When login times out, the login trail is terminated.
8. Stay Timeout in Seconds: Timeout value for inactive connection.
9. Press Save/Apply to save and activate the settings.
