2-20 Chapter 2: Getting started
2.5.14 CPU Cache Voltage [Auto]
This item allows you to set the CPU Cache voltage. Increase the cache voltage when
increasing the ring frequency. Configuration options: [Auto] [Manual Mode] [Offset Mode]
[Adaptive Mode].
[Adaptive Mode] is available for some specific CPU types.
CPU Cache Voltage Override [Auto]
This item appears only when you set the CPU Cache Voltage to [Manual Mode] and allows
you to set the CPU Cache voltage override. The values range from 0.001V to 1.920V with a
0.001V interval.
Offset Mode Sign [+]
This item appears only when you set the CPU Cache Voltage to [Offset Mode] or [Adaptive
Mode] and allows you to set the offset mode sign. Configuration options: [+] [-]
CPU Cache Voltage Offset [Auto]
This item appears only when you set the CPU Cache Voltage to [Offset Mode] or
[Adaptive Mode] and allows you to set the CPU cache voltage offset. The values range
from 0.001V to 0.999V with a 0.001V interval.
Additional Turbo Mode CPU Cache Voltage [Auto]
This item appears only when you set the CPU Cache Voltage to [Adaptive Mode] and allows
you to set the additional turbo mode CPU cache voltage. The values range from 0.001V to
1.920V with a 0.001V interval.
Total Adaptive Mode CPU Cache Voltage [Auto]
This item appears only when you set the CPU Cache Voltage to [Adaptive Mode] and allows
you to set the total adaptive mode CPU cache voltage. The values range from 0.001V to
1.920V with a 0.001V interval.
2.5.15 CPU System Agent Voltage Offset Mode Sign [+]
This item allows you to set the CPU system agent voltage offset mode sign. Configuration
options: [+] [-].
CPU System Agent Voltage Offset [Auto]
This item allows you to set the CPU system agent voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.16 CPU Analog I/O Voltage Offset Mode Sign [+]
This item allows you to set the CPU analog I/O voltage offset mode sign. Configuration
options: [+] [-].
CPU Analog I/O Voltage Offset [Auto]
This item allows you to set the CPU analog I/O voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
