2-16 Chapter 2: Getting started
tWRWR_dr [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
tWRWR_dd [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
Dec_WRD [Auto]
Configuration options: [Auto] [0] [1]
tRDWR [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
tRDWR_dr [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
tRDWR_dd [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
MISC
MRC Fast Boot [Enabled]
Allows you to enable or disable the MRC fast boot.
[Enabled] Enables the MRC fast boot.
[Disable] Disables the MRC fast boot.
DRAM CLK Period [Auto]
Configuration options: [Auto] [1] – [14]
Channel A DIMM Control [Enable Bot...]
Configuration options: [Enable Both DIMMS] [Disable DIMM0] [Disable DIMM1]
[Disable Both DIMMS]
Channel B DIMM Control [Enable Bot...]
Configuration options: [Enable Both DIMMS] [Disable DIMM0] [Disable DIMM1]
[Disable Both DIMMS]
Scrambler Setting [Optimized ...]
Configuration options: [Optimized (ASUS)] [Default (MRC)]
2.5.10 DIGI+ VRM
CPU Load-Line Calibration [Auto]
Load-line is defined by Intel VRM specification and affects CPU voltage. The CPU working
voltage will decrease proportionally to CPU loading. Higher value gets a higher voltage and
better overclocking performance, but increases the CPU and VRM thermal conditions. This
item allows you to adjust the voltage range from the following percentages to boost the
system performance: 0% (Regular), 25% (Medium), 50% (High), 75% (Ultra High), and 100%
(Extreme). Configuration options: [Auto] [Regular] [Medium] [High] [Ultra High] [Extreme]
The actual performance boost may vary depending on your CPU specification.
