ASUS CS-B 2-13
Target Cache Speed : xxxxMHz
Displays the target Cache speed.
Target DMI/PEG Clock : xxxxMHz
Displays the target DMI/PEG clock.
Target CPU Graphics Speed : xxxxMHz
Displays the target CPU Graphics speed.
2.5.1 ASUS MultiCore Enhancement [Enabled]
[Auto] Default set to [Auto] for maximum performance under XMP/Manual/User-
defined memory frequency mode.
[Disabled] Allows you to set to default core ratio settings.
2.5.2 CPU Core Ratio [Auto]
Allows you to set the CPU core ratio automatically or manually.
[Auto]
Sets all CPU Core Ratio to Intel ® CPU default settings automatically.
[Sync All Cores] Allows you to set CPU Core Ratio settings for all cores.
[Per Core]
Allows you to set CPU Core Ratio individually.
The following two items appear only when you set the CPU Core Ratio to [Sync All
Cores] or [Per Core].
1-Core Ratio Limit [Auto]
Select [Auto] to apply the CPU default Turbo Ratio setting or manually assign a 1-Core
Limit value, which should be higher than or equal to the 2-Core Ratio Limit.
2-/3-/4-Core Ratio Limit [Auto]
These items become configurable only when you set the CPU Core Ratio item to [Per
Core].
2.5.3 Min. CPU Cache Ratio [Auto]
Allows you to set the minimum CPU Cache Ratio.
2.5.4 Max. CPU Cache Ratio [Auto]
Allows you to set the maximum CPU Cache Ratio.
2.5.5 BCLK Frequency: DRAM Frequency Ratio [Auto]
Allows you to set the BCLK frequency to DRAM frequency ratio.
[Auto]
The BCLK frequency to DRAM frequency is set to its optimized settings.
[100:133] The BCLK frequency to DRAM frequency is set to 100:133.
[100:100] The BCLK frequency to DRAM frequency is set to 100:100.
