2.2.4 Layout contents
Sockets/Slots Page
1. CPU socket 2-6
2. DDR2 DIMM sockets 2-13
3. PCI Express/PCI slots 2-18
Jumpers Page
1. Clear RTC RAM (CLRTC1) 2-19
2. CPU fan pin selection (3-pin FM_CPU1, FM_CPU2) 2-20
3. USB device wake-up (3-pin USBPW12, USBPW34, USBPW56, 2-20
USBPW78)
4. Keyboard power (3-pin KBPWR1) 2-21
5. Gigabit LAN controller setting (3-pin LAN_EN1) 2-21
6. VGA graphics controller setting (3-pin VGA_EN1) 2-22
7. RAID select (3-pin RAID_SEL1) 2-22
8. BIOS recovery (3-pin RECOVERY1) 2-23
Rear panel connectors Page
1. PS/2 mouse port (green) 2-24
2. Parallel port 2-24
3. PS/2 keyboard port (purple) 2-24
4. USB 2.0 ports 1 and 2 2-24
5. Serial (COM1) port 2-24
6. VGA port 2-24
7. LAN (RJ-45) port 2-24
