ASUS P5MT-MX/C 6-5
To an existing Windows ® 2000/2003 Server OS
To install the RAID controller driver on an existing
Windows ® 2000/2003 Server OS:
1. Restart the computer, then log on with Administrator privileges.
2. Windows
® automatically detects the RAID controller and displays a
New Hardware Found window. Click Cancel.
3. Right-click the My Computer icon on the Windows ® desktop , then
select Properties from the menu.
4. Click the Hardware tab, then click the Device Manager button to
display the list of devices installed in the system.
Intel Matrix Storage
Select “Intel(R) 82801GR/GH SATA RAID Controller (Desktop ICH7RDH)”
for Intel Matrix Storage RAID mode from the list, then press .
If you configured SATA as AHCI Mode in the BIOS setup utility of IDE
Configuration, first install the Intel SATA AHCI Driver during windows
setup. Then, select the “Intel(R) 82801GR/GH SATA AHCI Controller
(Desktop ICH7RDH)” from the list. Refer to section “6.1.1 Creating a
RAID driver disk” to create the Intel SATA Driver for windows system.
6. The Windows ® 2000/2003 Setup loads the RAID controller drivers
from the RAID driver disk. When prompted, press to continue
installation.
7. Setup then proceeds with the OS installation. Follow screen
instructions to continue.
