ASUS P5MT-MX/C 6-7
To verify the RAID controller driver installation:
1. Right-click the My Computer icon on the Windows ® desktop , then
select Properties from the menu.
2. Click the Hardware tab, then click the Device Manager button.
3. Click the “+” sign before the item SCSI and RAID controllers.
When you installed the Intel ® ICH7R SATA RAID controller driver,
the Intel(R) 82801GR/GH SATA RAID Controller item should appear.
4. Right-click the RAID controller driver item, then select Properties from
the menu.
5. Click the Driver tab, then click the Driver Details button to display the
RAID controller drivers.
6. Click OK when finished.
When you installed the LSI logic embedded SATA RAID driver, the LSI Logic
Embedded SATA RAID item should appear.
