Audio Realtek ® ALC892 8-channel high definition audio CODEC
- Absolute Pitch 192khz/24bit True BD Lossless Sound
- Supports jack-detection, multi-streaming and front panel
jack-retasking
- Optical S/PDIF out ports at back I/O
USB ASMedia USB 3.0 controller- supports ASUS USB 3.0 Boost
UASP Mode
- 2 x USB 3.0/2.0 ports at back panel (blue)
Intel ® Z77 Express Chipset - supports ASUS USB 3.0 Boost
UASP Mode*
- 2 x USB 3.0/2.0 ports at mid-board for front panel support
- 2 x USB 3.0/2.0 ports at back panel (blue)
Intel ® Z77 Express Chipset
- 8 x USB 2.0/1.1 ports (6 ports at mid-board, 2 ports at back
panel)
* The USB 3.0 ports only support Windows 7 or later versions.
UASP standard only supports Windows 8.
ASUS Unique Features ASUS Dual Intelligent Processors 2 with DIGI+ VRM:
ASUS Digital Power Design
- Industry leading Digital 8-Phase Power Design (6-phase for
CPU, 2-phase for iGPU)
- ASUS DIGI+ VRM Utility
ASUS EPU
- EPU, EPU switch
ASUS TPU
- Auto Tuning, TurboV, GPU Boost, TPU switch
ASUS Exclusive Features:
- Network iControl featuring instant network bandwidth
domination for top network program in use.
- USB 3.0 Boost featuring the latest USB 3.0 UASP standard
- AI Charger+
- Disk Unlocker
- AI Suite II
- Anti Surge
- MemOK!
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Heat-sink solution
- ASUS Fan Xpert+
ASUS EZ DIY:
- ASUS USB BIOS Flashback with USB BIOS Flashback
Wizard for EZ BIOS download scheduling
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user
interface
- ASUS O.C. Tuner
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
ASUS Q-Design:
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector
(continued on the next page)
P8Z77-M PRO specifications summary
