ASUS P8Z77-M PRO 3-17
Chapter 3
White Yellow Pink Red
CPU Manual
Voltage
0.8V–0.945V 0.95V–0.99V 0.995V–1.035V 1.04V–1.99V
CPU Offset
Voltage
0.005V–0.05V 0.055V–0.095V 0.1V–0.14V 0.145V–0.635V
iGPU Manual
Votlage
0.8V-0.945V 0.95V-0.99V 1.995V-1.035V 1.04V-1.99
iGPU Offset
Voltage
0.005V–0.05V 0.55V–0.095V 0.1V–0.14V 0.145V–0.635V
DRAM Voltage 1.185V–1.575V 1.58V–1.65V 1.655V–1.725V 1.73V–2.135V
PCH Voltage 0.735V–1.100V 1.105V–1.155V 1.160V–1.205V 1.210V–1.685V
VCCSA Voltage [Auto]
Allows you to set the VCCSA voltage. The values range from 0.925V to 1.025V with a 0.1V
interval.
CPU PLL Voltage [Auto]
Allows you to set the CPU and PCH PLL voltage. The values range from 1.8V to 1.9V with a
0.1V interval.
CPU Spread Spectrum [Auto]
[Auto] Automatic configuration.
[Disabled] Enhances the BCLK overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
