Mount Thermostat to Wallplate

1.Align the terminal screw blocks with the pins on the back of the thermostat. Push the
thermostat straight onto the wallplate until it snaps into place. See Fig 24.

Fig. 24. Mount thermostat to wallplate.

WALLPLATE

TERMINAL SCREW BLOCK

PINS ON BACK OF

THERMOSAT
