Comfort Stat CDT901 User Manual

Page 18

background image

CDT900 Series Touchscreen Programmable Thermostata

Fig. 6. Mounting wallplate.

17

WALL

WIRES THROUGH
WALL AND WIRE
SLOT

WALL ANCHORS

M0UNTING
HOLES(2)

M0UNTING
SCREWS(2)
