Figure 5 - pc to console port – Net Optics iBypass 40G User Manual
Page 11
11
8. Go to Configure the IP section and follow the instructions to set a new IP
address.
For more information about using the iBypass 40G Switch CLI, enter help to display
command information or see the iBypass 40G Switch User Guide for more details.
PC on the same subnet
as iBypass 40G switch
Connect Cat 5e cable from
Management port to PC
Ethernet
Figure 5 - PC to Console Port
