MIL-PRF-55310/29C
2
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) for three place decimals and ±.02 (0.5 mm) for two
place decimals.
4 All pads with NC functions are not connected externally.
FIGURE 1. Dimensions and configuration - Continued.
Ltr Inches mm
Min Max Min Max
A .454 .466 11.53 11.84
B .465 SQ .495 SQ 11.81 SQ 12.57 SQ
C --- .085 --- 2.16
D .033 .047 0.84 11.94
E .015 .025 0.38 0.63
F .055 .070 1.40 1.78
G .355 SQ .365 SQ 9.02 SQ 9.27 SQ
H .035 .045 0.89 1.14
